Musabeyli Dam
Fill Volume 3,020,000 m³
Place
Yozgat Province, Turkey
Client
NVS İnşaat
Year
2004 - 2008
Description of the Project
Dam is a clay core sandy-gravel fill type. Within the scope of the Project, Cofferdams, spillway, bottom outlet, diversion tunnel, intake structure, downstream channel improvement, material access roads, main access road,s electrical and mechanical final design drawings have been prepared. Topographic surveys, geotechnical investigations, determining borrow areas of construction materials, hydraulic studies, dam body static-dynamic analysis, seismic hazard analysis, related cost analysis, financial and economic analysis are among the services provided.
Main Features
- Dam body type: Clay core sandy gravel dam
- Height from the foundation: 65.00 m
- Maximum storage volume: 48.60 million m³
- Dam fill volume: 3,020,000 m³
